Advantages & Features

• Reinforced light-duty flail mower with 4 mm body, 6 mm side plates, and 76 × 10 mm rotor

• Hardened 500 g hammers suitable for grass and branches up to 3 cm diameter

• Cast iron 540 rpm gearbox with freewheel

• Long-life heavy-duty bearings

• Electronically balanced rotor with hammers or optional blades

• Front safety protection flaps

• Adjustable working height via side skids

• Adjustable rear roller with scraper

• Belt transmission with 3 toothed belts and external tensioner

• Universal Category I–II three-point linkage

• CE European safety certification

Transmission & Maneuverability

• Standard synchronized transmission with shuttle

• 12 forward / 12 reverse gears, offering more working speed options than most tractors in its class

• Hydrostatic power steering with adjustment, reducing operator fatigue and improving control

• Heavy-duty Japanese-spec differential with 48° steering angle

• Extremely tight turning radius: only 2.8 m

Hydraulics & Implement Handling

• High-capacity hydraulic system for demanding implements

• 4 rear quick couplers (2 pairs) for fast and easy implement connection

• Adjustable 3-point hitch arms

• Category I three-point linkage

• Maximum lift capacity: 820 kg

• Ergonomic loader joystick, easily accessible for comfortable loader operation

Cabin Comfort & Ergonomics

• Spacious enclosed cabin with Air Conditioning & Heating ❄️🔥

• Equipped with side mirrors, front windshield wiper, interior lighting, and flat floor

• Modern ergonomic layout for a comfortable and fatigue-free working environment

• Sensitivity-adjustable control levers for precise and smooth operation

Practical Equipment & Versatility

• Wide tyre options: agricultural, industrial, or turf tyres

• Adjustable tow hitch for increased tractor versatility

• Rear adjustable work light for improved visibility in low-light conditions 🌙

• 12V power socket for tools and accessories 🔌

• Large fuel tank for long working hours without frequent refueling

• Easy-opening hood for quick access and simplified maintenance

Dimensions & Weight

• Length (without weights): 3137 mm

• Overall width (with tyres): 1458 mm

• Wheelbase: 1754 mm

• Height: 2237 mm (1227 mm at fender)

• Total weight: 1858 kg

• Trailer load capacity: 3380 kg

Tyres

• Front: 7 – 16

• Rear: 12.4 – 24

Hydraulic System

• Total flow: 51.9 L/min

• Steering pump: 20.8 L/min

• Main pump: 31.1 L/min

• Rear hydraulic outlets: 4

Engine

• Type: 3-cylinder, indirect injection

• Model: Mitsubishi L3CRV-T4

• Maximum engine power: 49 HP

• Rated engine power: 41 HP

• PTO power: 32 HP

• Displacement: 1879 cc

• Fuel tank capacity: 47 L

Transmission

• Type: Synchromesh

• Gearbox: F12 × R12

• Working speed:

  • 1.1 – 27 km/h (Synchro Shuttle)

  • 0 – 25.1 km/h (HST)

Ideal Applications

• Vineyards 🍇

• Orchards 🌳

• Specialized and narrow-row farming

• Professional agricultural operations requiring comfort and efficiency
