Product Description

The GRAECUS EKN135 light-duty flail mower is designed for compact and low-horsepower tractors such as Kubota, Iseki, Yanmar, Pasquali and similar models from 8–30 HP. It is ideal for garden maintenance, small farms, orchards, and property management.

Unlike flail mowers equipped with Y-blades, the EKN series uses 500 g hardened hammers combined with a reinforced Ø76 mm rotor with 10 mm thickness, creating higher inertia and improved cutting efficiency. This design allows the mower to easily handle tall grass, weeds, bushes, brambles, and small branches.

The cutting height can be quickly adjusted using the rear roller and the side skids, allowing the operator to adapt the machine to different terrains and working conditions.

Built with a reinforced steel body, durable bearings, and a reliable belt drive system, the EKN135 offers smooth operation, durability, and efficient cutting performance.

The price includes the PTO shaft T4-80 with plastic safety cover.

GRAECUS EKN135

Advantages & Features

  • Reinforced light-duty flail mower with 4 mm body, 6 mm side plates, and 76 × 10 mm rotor

  • Hardened 500 g hammers suitable for grass and branches up to 3 cm diameter

  • Cast iron 540 rpm gearbox with freewheel

  • Long-life heavy-duty bearings

  • Electronically balanced rotor with hammers or optional blades

  • Front safety protection flaps

  • Adjustable working height via side skids

  • Adjustable rear roller with scraper

  • Belt transmission with 3 toothed belts and external tensioner

  • Universal Category I–II three-point linkage

  • CE European safety certification



Specification Value
Weight 186 kg
Tractor Power 20 – 30 HP
Machine Width 1440 mm
Length 700 mm
Height 750 mm
Working Width 1350 mm
Side Shift 610 / 740 mm (left) – 510 / 840 mm (right)
Hammers 24 pcs
Blades (optional) 48 pcs
Rotor 76 × 10 mm
Drive Belts 3 pcs
PTO Speed 540 rpm

1.430,00
