GRAECUS EKN85

Advantages & Features

• Reinforced light-duty construction with 4 mm body, 6 mm side plates, and rotor 76 × 10 mm

• Special hardened 500 g hammers, suitable for grass and branches up to 3 cm in diameter

• Cast iron gearbox, 540 rpm, with freewheel

• Long-life bearings

• Dynamically balanced rotor with hammers or optional blades

• Front safety protection flaps

• Adjustable working height via skids

• Adjustable rear roller with scraper

• Power transmission via 3 reinforced belts with external tensioner

• Universal 3-point linkage (Category I–II: ø 19.0–22.0 mm / 28.0 mm)

• CE European safety certification

The price includes PTO shaft T4-80 with plastic safety guard.

Technical Specifications

• Weight: 150 kg

• Power Requirement: 8 – 30 HP

• Width: 940 mm

• Length: 700 mm

• Height: 750 mm

• Working Width: 850 mm

• Side Shift:

  • Left: 460 / 390 mm

  • Right: 360 / 490 mm

• Hammers: 15 pcs

• Blades (optional): 30 pcs

• Rotor: 76 × 10 mm

• Belts: 3 pcs
