Description

The GRAECUS EKN flail mower is designed for low horsepower tractors such as Kubota, Iseki, Yanmar, and Pasquali (8–30 HP) and is ideal for use in gardens and small farms.

Unlike flail mowers equipped with Y-blades, this mower features high inertia generated by 500 g hammers and a new heavy-duty rotor shaft (Ø76 mm with 10 mm thickness).

Even very tall grass, bushes, small branches, and brambles are not a problem for this mower.
The cutting height can be easily adjusted using the rear adjustable roller and the side skids.

GRAECUS EKN95

Advantages & Features

  • New reinforced light-duty flail mower with 4 mm body, 6 mm side plates, and rotor 76 × 10 mm

  • Hardened 500 g hammers, suitable for grass and branches up to 3 cm diameter

  • Cast iron gearbox (540 rpm) with freewheel

  • Long-life bearings

  • Digitally balanced rotor with hammers or optional blades

  • Front protective metal flaps

  • Working height adjustment via skids

  • Adjustable rear roller with scraper

  • Power transmission via 3 toothed belts with external tensioner

  • Universal 3-point hitch (Category I–II)
    (ø 19.0–22.0 mm / 28.0 mm)

  • European CE safety certification

The price includes the PTO drive shaft T4-80 with plastic safety cover.

Specification Details
Weight 154 kg
Tractor Power 10 – 30 HP
Width 1040 mm
Length 700 mm
Height 750 mm
Working Width 950 mm
Offset ← 510/440 mm || 410/540 mm →
Hammers 15 pcs
Blades (optional) 30 pcs
Rotor 76 × 10 mm
Belts 3 pcs

1.190,00

SKU: 007141 Category:
