OLIVE HARVEST

Power Supply Notes

If you choose to use a commercial or DIY generator instead of a car battery, always measure the generator’s output with a voltmeter. Ensure the voltage is stabilized and does not exceed 14V, to prevent potential damage.

High-Performance 48-Rod Head

The ASTERAS MAX features a specially developed harvesting head with 48 carbon-fibre rods and 2 T8 aluminium eccentric counterweights.

The patented Greek-made mechanism combines the flexibility of carbon fibre with a wide-range pulsating movement to achieve efficient harvesting while minimizing unnecessary impact on the tree.

Compared with the ASTERAS CF, the MAX features an additional rod holder with 8 extra carbon-fibre rods, increasing the harvesting range and improving penetration into dense foliage.

T8 Aluminium Eccentric Counterweights

The two T8 aluminium eccentric counterweights are designed to provide a powerful yet balanced pulsating movement.

Combined with the 48 carbon-fibre rods, they create a wide harvesting action that helps maximize productivity while maintaining controlled contact with the olive tree.

Powerful BOSCH 400W Motor

The ASTERAS MAX is equipped with a BOSCH 400W DC electric motor, delivering up to 2,000 pulsating movements per minute at 16V DC.

The system includes a 35A ON/OFF switch and a reduction mechanism that converts the motor’s rotational movement into the pulsating action of the harvesting heads.

It can operate from a generator or an 80–100A battery with converter, and can also be connected to a car battery when used with the appropriate converter.

Carbon-Fibre Construction

The carbon-fibre tube provides an excellent combination of strength, low weight and rigidity.

With an initial length of 2.50–2.80m and a total weight of approximately 2.95kg, the ASTERAS MAX is designed to provide excellent reach without unnecessarily increasing operator fatigue.

High Harvesting Performance

The ASTERAS MAX can achieve an estimated harvesting output of 200–250kg of olives, depending on the variety, tree condition and harvesting conditions.

Its 13-metre power cable provides practical freedom of movement in the field.

Product Specifications

Model: ASTERAS MAX ALL CARBON 6×6
Movement: Pulsating vibration – 6×6 system
Construction: Carbon Fibre Tube
Initial Length: 2.50–2.80m
Head: T8 aluminium eccentric counterweights
Carbon-Fibre Rods: 48
Head Speed: 2,000 rpm @ 16V DC
Motor: BOSCH DC 400W
Motor Voltage: 14–16V / 400W or 28–30V / 400W for 24V motor
Weight: 2.95kg
Cable Length: 13m
Harvesting Output: 200–250kg of olives
Average Consumption: Approx. 8A/hour
Power Supply: Generator or 80–100A battery with converter

Greek-Made Technology for Professional Olive Harvesting

The ASTERAS MAX ALL CARBON 6×6 represents an evolution of the ASTERAS CF, combining 6×6 independent movement, 48 carbon-fibre rods, T8 aluminium eccentric counterweights and a powerful BOSCH 400W motor.

Designed and manufactured in Greece, it is built to deliver maximum harvesting range, efficient penetration and high productivity, while keeping vibration transmission to the operator to a minimum.

Durable Aluminium Construction

The 2.80m aluminium shaft offers a practical combination of strength, low weight and easy handling.

Metal connections reinforce the construction and contribute to the overall durability of the tool.

The machine weighs approximately 2.6kg, making it one of the lighter options in its category.

Easy Maintenance & Safety

The GOLD PRO 4×4 is designed with maintenance and reliability in mind.

Key features include:

• Metal head gears
• Metal central motor gear
• Grease-free? — No: lubrication should be performed according to the manufacturer’s maintenance instructions
• Single safety pin on the motor
• Low-cost maintenance and replacement parts
• 2-year operating warranty
• 5-year warranty on the metal head gears

Flexible Silicone Cable

The machine is supplied with a 15-metre flexible 2×3mm silicone cable, providing practical freedom of movement during harvesting and durability for field use.

Product Specifications

Model: MINOS NIK GOLD PRO 4×4 BRUSHLESS
Type: Electric Olive Harvester
Movement: Pulsating vibration
System: 4×4 independent movement
Motor: 1000W Brushless
Voltage: 12V / 24V
Shaft: Aluminium
Length: 2.80m
Rods: 32
Head: Metal gears
Head Gear Warranty: 5 years
Operating Warranty: 2 years
Weight: Approx. 2.6kg
Cable: 15m flexible 2×3mm silicone
Speed Control: Yes

Powerful, Lightweight & Built for Professional Use

The MINOS NIK GOLD PRO 4×4 BRUSHLESS combines a 1000W Brushless motor, 4×4 independent movement, 32-rod head and lightweight aluminium construction to provide a powerful and practical solution for olive harvesting.

With adjustable pulsating movement, durable metal gearing and compatibility with 12V and 24V systems, it offers the flexibility and performance required for both professional and demanding olive harvesting applications.

Product Specifications

Movement Type: Pulsating vibration
Operating Voltage: 12V DC
Motor: 800W Brushless
Speed: 700–1,550 pulses/min
Initial Length: 2.30m
Maximum Length: 3.30m with extension
Extension: 1.0m
Head: Double comb
Mechanism: 2 eccentrics, 2 connecting rods
Gears: Steel
Carbon-Fibre Rods: 8
Maximum Harvesting Width: 54cm
Weight: Approx. 2.3kg without cable
Cable Length: 13m
Harvesting Performance: 200–270kg/hour
Average Consumption: Approx. 6A/hour
Power Supply: 80–100A battery or generator with voltage stabilizer
Manufacturing: 100% Greek-made

Greek-Made Professional Olive Harvesting Technology

The Amolivo combines a powerful Brushless motor, patented double-comb carbon-fibre technology and adjustable vibration control to deliver fast, efficient and controlled olive harvesting.

With its specialized carbon-fibre protection, it is also an excellent choice for table olives, helping achieve efficient harvesting while minimizing fruit damage.
